Jungheinrich EJC 212-220 - Assemblies

0306.GB
B 2
2 Assemblies
M
1)
The truck must not be operated without the emergency disconnect (see chapter C).
Item EJC 212-220 Description
1 o Charge display
2 t Key switch
3 o CANCODE keypad
o ISM Access Module
4 t Battery discharge indicator /hourmeter
o CANDIS display instrument
5 t Tiller and grip
6 t Crawl button
7 t Travel switch
8 t Collision safety switch
9 t Mast
10 t Mast guard; optional protective frame
11 t Battery panel
12 t Battery connector (emergency disconnect)
1)
13 t Lift mechanism
14 o Charger
15 t Front panel
16 t Caster wheel
17 o Document pocket
18 t Drive wheel
t = Standard equipment o = Optional Equipment
1
2
3
4
5
7
8
7
6
9
10
11
12
13
14
15
16
18
17
