Jungheinrich EJC 212-220 - Standard Version Specifications; Performance Data for Standard Trucks; Dimensions EJC 212;214

B 3
0306.GB
3 Standard Version Specifications
Z
Technical specification details in accordance with VDI 2198. Technical modifications
and additions reserved.
3.1 Performance data for standard trucks
3.2 Dimensions EJC 212/214
1)
for 100 mm free lift (h2)
2)
DZ + 35 mm
Description EJC 212 EJC 214 EJC 216 EJC 220
Q Rated capacity 1200 1400 1600 2000 kg
c Load centre distance
Standard fork length
600 600 600 600 mm
Travel speed
w. nominal load / w.o. load
6,0 / 6,0 6,0 / 6,0 6,0 / 6,0 6,0 / 6,0 km/h
Raise lift speed
w. nominal load / w.o. load
15 / 26 15 / 26 14 / 26 10 / 18 cm/s
Lowering speed
w. nominal load / w.o. load
40 / 40 40 / 40 40 / 40 40 / 40 cm/s
Max. gradeability (5 min rating)
w / w.o. load
8 / 16 8 / 16 7 / 16 7 / 16 %
Description EJC 212 EJC 214
h1 Height (retracted) ZT
1)
1750 – 2650 1750 – 2650 mm
h1 Height (retracted) ZZ
1)
1700 – 2600 1700 – 2600 mm
h1 Height (retracted) DZ
1)
1830 – 2250 1830 – 2250 mm
h2 Free lift ZT 100 100 mm
h2 Free lift ZZ 1223 – 2123 1223 – 2123 mm
h2 Free lift DZ 1356 – 1776 1356 – 1776
h3 Lift (mast-dependent) ZT 2500 – 4300 2500 – 4300 mm
h3 Lift (mast-dependent) ZZ 2500 – 4300 2500 – 4300 mm
h3 Lift (mast-dependent) DZ 4090 – 5350 4090 – 5350 mm
h4 Extended mast height ZT 2977 – 4777 2977 – 4777 mm
h4 Extended mast height ZZ 2977– 4777 2977– 4777 mm
h4 Extended mast height DZ 4565 – 5825 4565 – 5825 mm
h13 Load fork lowered 90 90 mm
h14 Tiller height in min/max travel
position
768/1298 768/1298 mm
y Wheelbase 1277/1357 1277/1357 mm
l1 Overall length 1896/1976 1896/1976 mm
l2 Headlength 746/826 746/826 mm
b1 Truck width 802 802 mm
b5 Width across forks 570 570 mm
m2 Ground clearance 30 30 mm
Ast Working aisle width
1000 x 1200 crosswise
2364/2443
2)
2364/2443
2)
mm
Ast Working aisle width
800 x 1200 longit. (in accordance
with VDI)
2337/2416
2)
2337/2416
2)
mm
Wa Turning radius in crawl mode
(tiller vertical)
1488/1567 1488/1567 mm
