Jungheinrich EJC 212-220 - Capacity

0306.GB
B 8
4.1 Truck data plate
Z
For queries regarding the truck or ordering spare parts always quote the truck serial
number (30).
4.2 Capacity
F
The stated capacities apply only for battery weights as indicated on the data plate.
The lower plate (18) gives the capacity (Q in kg) of the truck as a function of the load
centre of gravity distance (D in mm) and lift height (H in mm) in tabular form
(illustration as example only).
Item Description Item Description
29 Type 35 Manufacturer’s logo
30 Serial no. 36 Min./max. battery weight (kg)
31 Rated capacity (kg) 37 Output (kW)
32 Battery voltage (V) 38 Load centre of gravity (mm)
33 Net weight w.o. battery (kg) 39 Year of manufacture
34 Manufacturer 40 Option
34
33
32
31
30
39
40
38
37
36
35
29
-Nr.
Serien-Nr.
Dmm
Hmm
Qkg
18
