Jungheinrich EJC 212-220 - Dimensions EJC 216;220

0306.GB
B 4
3.3 Dimensions EJC 216/220
1)
for 100 mm free lift (h2)
2)
DZ + 35 mm
Description EJC 216 EJC 220
h1 Height (retracted) ZT
1)
1750 – 2650 1750 – 2650 mm
h1 Height (retracted) ZZ
1)
1700 – 2600 1700 – 2600 mm
h1 Height (retracted) DZ
1)
1830 – 2250 1830 – 2250 mm
h2 Free lift ZT 100 100 mm
h2 Free lift ZZ 1173 – 2073 1223 – 2123 mm
h2 Free lift DZ 1306 – 1726 1356 – 1776
h3 Lift (mast-dependent) ZT 2400 – 4200 2500 – 4300 mm
h3 Lift (mast-dependent) ZZ 2400 – 4200 2500 – 4300 mm
h3 Lift (mast-dependent) DZ 3990 – 5250 4090 – 5350 mm
h4 Extended mast height ZT 2927 – 4727 2977 – 4777 mm
h4 Extended mast height ZZ 2927– 4727 2977– 4777 mm
h4 Extended mast height DZ 4515 – 5775 4565 – 5825 mm
h13 Load fork lowered 90 90 mm
h14 Tiller height in min/max travel
position
768/1298 768/1298 mm
y Wheelbase 1277/1357 1277/1357 mm
l1 Overall length 1896/1976 1896/1976 mm
l2 Headlength 746/826 826 mm
b1 Truck width 802 802 mm
b5 Width across forks 570 570 mm
m2 Ground clearance 30 20 mm
Ast Working aisle width
1000 x 1200 crosswise
2364/2443
2)
2364/2443
2)
mm
Ast Working aisle width
800 x 1200 longit. (in accordance
with VDI)
2337/2416
2)
2337/2416
2)
mm
Wa Turning radius in crawl mode
(tiller vertical)
1488/1567 1488/1567 mm
