Juniper AP43 User Manual

Figure 3: Antenna Connectors on the AP43E
Table 2: AP43 Components
Component Descripon
Reset A pinhole reset buon that you can use to reset the AP conguraon to the factory
default.
12VDC Input for an oponal 12 VDC power supply.
You must order this power supply (part number: DC-01) separately.
Eth0+PoE-in 100/1000/2500BASE-T RJ45 port that supports an 802.3at or 802.3bt PoE-powered
device
Eth1+PSE-out 10/100/1000BASE-T RJ45 port + 802.3af Power Sourcing Equipment (PSE) (if PoE-in is
802.3bt)
USB USB 2.0 port
IoT 8-pin port for digital input and output, analog input, and ground
Antenna connectors
(available only in
AP43E models)
Six reverse-polarity SubMiniature version A (RP-SMA) connectors (four dual-band for
client radios; two dual-band for the third radio)
Kensington lock Slot for a Kensington-style lock that you can use to secure the AP.
5
