Juniper AP43 - Mount an Access Point on a Single-Gang or 3.5-Inch or 4-Inch Round Junction Box

(Connued)
Hole Number Mounng Opon
2
• US double-gang juncon box
• Wall
• Ceiling
3
• US 4-in. square juncon box
4
• EU juncon box
Video: Aach the APBR-U Universal Mounng Bracket to an AP
Mount an Access Point on a Single-Gang or 3.5-Inch or 4-Inch Round
Juncon Box
You can mount an access point (AP) on a US single-gang or a 3.5-in. or 4-in. round juncon box by using
the universal mounng bracket (APBR-U) that we ship along with the AP. To mount an AP on a single-
gang juncon box:
1. Aach the mounng bracket to the single-gang juncon box by using two screws. Ensure that you
insert the screws in the holes marked 1 as shown in Figure 5 on page 16.
15
