Figure 14: Lock the Mounng Bracket (APBR-U) to a 9/16-in. or 15/16-in. T-Bar
3. Posion the AP such that the keyholes of the mounng bracket engage with the shoulder screws on
the AP. Slide and lock the AP in place.
Figure 15: Aach the AP to a 9/16-in. or 15/16-in. T-Bar
Video: Mount an AP on a 9/16ths-Inch or 15/16ths-Inch T-Bar
Mount an Access Point on a Recessed 15/16-Inch T-Bar
You'll need to use an adapter (ADPR-ADP-RT15) along with the mounng bracket (APBR-U) to mount
an access point (AP) on a recessed 15/16-in. ceiling T-bar. You need to order the ADPR-ADP-RT15
adapter separately.
1. Aach the ADPR-ADP-RT15 adapter to the T-bar.
22
