CHAPTER 6
Cable and Pinout Specifications
•
CTP2000 4WE&M Interface Connector Pinouts on page 43
•
CTP2000 FXS and FXO Interface Module Cables and Pinouts on page 45
•
T1/E1 Interface Module Pinouts on page 48
•
CTP2000 Serial Interface Module Pinouts on page 49
•
CTP2000 Series Console Cable Pinouts on page 58
•
CTP Fast Ethernet and Power Cables on page 63
CTP2000 4WE&M Interface Connector Pinouts
•
CTP2000 4WE&M RTM Connector A Pinouts on page 43
•
CTP2000 4WE&M Connector B Pinouts on page 44
CTP2000 4WE&M RTM Connector A Pinouts
See Table 13 on page 43 for connector A pinout information. See “CTP2000 4WE&M
Interface Module” on page 14 for signal definitions.
Table 13: CTP2000 4WE&M RTM Pinouts–Connector A
Connector A
PinSignalSignalPin
26Port 0 TPort 0 R1
27Port 0 T1Port 0 R12
28Port 0 EPort 0 SG3
29Port 0 MPort 0 SB4
30Port 1 TPort 1 R5
31Port 1 T1Port 2 R16
32Port 1 EPort 2 SG7
