Page #100 background imageLoading...
Page #100 background image
Table 23: Uplink Modules Connector Pinout Information for EX3200 and EX4200
Switches (continued)
Pin NamePin Number
Uplink_I2C_SDAC16
CPU_UPLINK_MDIOC17
Uplink_P26_LED1C18
UPLNK_PWR_OKC19
POWER (12V)C20
GNDD1
GNDD2
XAUI0_TX1ND3
GNDD4
XAUI0_TX3ND5
GNDD6
XAUI1_TX1ND7
GNDD8
XAUI1_TX3ND9
GNDD10
STX27ND11
GNDD12
STX25ND13
GNDD14
Uplink_RstD15
GNDD16
Uplink_Status_LED0D17
GNDD18
Copyright © 2010, Juniper Networks, Inc.76
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches
