Table 20: Optical Interface Support for Gigabit Ethernet SFP+ Transceivers in EX3200 and

EX4200 Switches

SpecificationsEthernet Standard

EX-SFP-10GE-USRModel Number10GBase-SR

10 GbpsRate

LCConnector Type

DualFiber Count

850 nmTransmitter Wavelength

–7.3 dBmMinimum Launch Power

–1.3 dBmMaximum Launch Power

–11.1 dBmMinimum Receiver Sensitivity

–9.9 dBmMaximum Input Power

MMFFiber Type

50/125 µm50/125

µm

62.5/125

µm

Core/Cladding Size

OM3OM3OM1Fiber Grade

1500

MHz/km

500

MHz/km

200

MHz/km

Modal Bandwidth

100 m

(328 ft)

30 m

(98.4 ft)

10 m

(32.8 ft)

Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 10.2 or laterSoftware required
