Table 19: Optical Interface Support for Fast Ethernet SFP Transceivers in EX3200 and EX4200

Switches

SpecificationsEthernet Standard

EX-SFP-1FE-FXModel Number100Base-FX

100 MbpsRate

LCConnector Type

DualFiber Count

1310 nmTransmitter Wavelength

–20 dBmMinimum Launch Power

–14 dBmMaximum Launch Power

–32.5 dBmMinimum Receiver Sensitivity

–8 dBmMaximum Input Power

MMFFiber Type

62.5/125 µmCore/Cladding Size

FDDI/OM1Fiber Grade

500 Mhz/kmModal Bandwidth

2 km (1.2 miles)Distance

Not availableDOM Support

Junos OS for EX Series switches, Release 9.2 or laterSoftware required
