Table 19: Optical Interface Support for Fast Ethernet SFP Transceivers in EX3200 and EX4200

Switches (continued)

SpecificationsEthernet Standard

EX-SFP-1FE-LXModel Number100Base-LX

100 MbpsRate

LCConnector Type

DualFiber Count

1310 nmTransmitter Wavelength

–15 dBmMinimum Launch Power

–8 dBmMaximum Launch Power

–31.5 dBmMinimum Receiver Sensitivity

–8 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

10 km (6.2 miles)Distance

Not availableDOM Support

Junos OS for EX Series switches, Release 9.5 or laterSoftware required
