Table 23: Uplink Modules Connector Pinout Information for EX3200 and EX4200
Switches (continued)
Pin NamePin Number
Uplink_P28_ LED2H8
XAUI1_RX3PH9
GNDH10
SRX27PH11
Uplink_XAUI_MDCH12
SRX25PH13
GNDH14
Serial_RXH15
GNDH16
Uplink_P25_LED1H17
Uplink_P28_LED0H18
POWER (12V)H19
POWER (12V)H20
GNDI1
GNDI2
GNDI3
GNDI4
GNDI5
GNDI6
GNDI7
GNDI8
GNDI9
GNDI10
Copyright © 2010, Juniper Networks, Inc.80
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches
