Table 24: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)

Pin NamePin Number

P1TXP1A5

P1TXN1A6

GNDA7

P1TXP2A8

P1TXN2A9

GNDA10

P1TXP3A11

P1TXN3A12

GNDA13

NCA14

NCA15

GNDA16

NCA17

NCA18

NCA19

NCA20

NCA21

GNDA22

P2TXP0A23

P2TXN0A24

GNDA25

P2TXP1A26

P2TXN1A27

GNDA28
