Table 18: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP

Transceivers in EX3200 and EX4200 Switches (continued)

SpecificationsEthernet Standard

EX-SFP-1GE-LXModel Number1000Base-LX

1000 MbpsRate

LCConnector Type

DualFiber Count

1310 nmTransmitter Wavelength

–9.5 dBmMinimum Launch Power

–3 dBmMaximum Launch Power

–25 dBmMinimum Receiver Sensitivity

–3 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

10 km (6.2 miles)Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 9.0 or laterSoftware required
