Table 18: Optical Interface Support and Copper Interface Support for Gigabit Ethernet SFP

Transceivers in EX3200 and EX4200 Switches (continued)

SpecificationsEthernet Standard

EX-SFP-GE40KT15R13Model Number1000Base-BX-D

1000 MbpsRate

LCConnector Type

SingleFiber Count

1550 nmTransmitter Wavelength

1310 nmReceiver Wavelength

–6.5 dBmMinimum Launch Power

2 dBmMaximum Launch Power

–3 dBmMinimum Receiver Sensitivity

–23 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

40 km (24.8 miles)Distance

AvailableDOM Support

Junos OS for EX Series switches, Release 9.5 or laterSoftware required
