Table 19: Optical Interface Support for Fast Ethernet SFP Transceivers in EX3200 and EX4200

Switches (continued)

SpecificationsEthernet Standard

EX-SFP-FE20KT15R13Model Number100Base-BX-D

100 MbpsRate

LCConnector Type

SingleFiber Count

1550 nmTransmitter Wavelength

1310 nmReceiver Wavelength

–14 dBmMinimum Launch Power

–8 dBmMaximum Launch Power

–45 dBmMinimum Receiver Sensitivity

–8 dBmMaximum Input Power

SMFFiber Type

9/125 µmCore/Cladding Size

–Modal Bandwidth

20 km (12.4 miles)Distance

Not availableDOM Support

Junos OS for EX Series switches, Release 9.3 or laterSoftware required
