NOTE: The right and left base bracket cannot be interchanged (see Figure 56 on page 152).
Figure 56: Front Panel Mounting Hardware
g050602
2
1
3
3—1— Left base bracketLatch brackets
2—Right base bracket
4. Use the Phillips screwdriver to attach two mounting screws to the right base bracket at the bottom
right side of the chassis frame.
5. Use the Phillips screwdriver to attach two mounting screws to the latch bracket at the top left of the
chassis frame (see Figure 57 on page 153 for MX10008 installation).
152
