Juniper MX204 - Page 18

NOTE: For console devices, congure the serial port to the following values:
• Baud rate—9600
• Parity—N
• Data bits—8
• Stop bits—1
• Flow control—none
Figure 15: Console and Auxiliary Cable Connector
Figure 16: Connecng the MX204 Router to a Management Console Through a Console Server
Figure 17: Connecng the MX204 Router Directly to a Management Console
15
