Juniper MX204 - Connect a Time-Of-Day Device to the Router; Connect a BITS External Clocking Device to the Router

Table 4: Clocking Port on the MX204 Router
Callout Label Descripon
5
(See Figure 13 on page 13)
10MHz
1PPS
GPS input and output ports.
Connect a Time-of-Day Device to the Router
A me-of-day port—labeled ToD—on the front panel of the router enables you to connect external
ming devices.
To connect the router to a ToD external ming device:
1. Aach an electrostac discharge (ESD) grounding trap on your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Plug one end of the RJ-45 cable into the ToD port on the front panel of the router.
3. Plug the other end of the RJ-45 cable into the ToD ming device.
4. Verify that the LEDs for the ToD port on the router are lit steadily green.
5. Congure the port. See
Conguring Clock Synchronizaon Interface on MX Series Routers .
Table 5: Time-of-Day Port on the MX204 Router
Callout Label Descripon
13
(See Figure 13 on page 13)
ToD ToD RJ-45 port with LED.
Connect a BITS External Clocking Device to the Router
The router has an external building-integrated ming supply (BITS) port—labeled BITS—on the front
panel of the router.
To connect the router to a BITS external clocking device:
1. Aach an electrostac discharge (ESD) grounding trap on your bare wrist, and connect the strap to
one of the ESD points on the chassis.
2. Plug one end of the RJ-45 cable into the internal clock port on the router.
3. Plug the other end of the RJ-45 cable into the BITS external clocking device.
17
