Juniper MX204 User Manual

Figure 4: ESD Points on the MX204 Router
1—
ESD point
Step 1: Prepare the Site for MX204 Installaon
IN THIS SECTION
MX204 Router Rack Requirements | 3
Router Clearance Requirements | 6
Router Cooling and Airow Requirements | 7
Tools Required to Prepare the MX204 Router for Installaon | 8
MX204 Router Rack Requirements
The MX204 router can be installed in a standard 19-in. rack. Many types of racks are acceptable,
including four-post (telco) racks and open-frame racks. Table 1 on page 4 summarizes rack
requirements and specicaons for the router.
3

Juniper MX204 Specifications

General

Cooling type	Active
Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Number of fans	3 fan(s)
AC input voltage	100 - 240 V
Number of power supply units	2
Operating altitude	0 - 1828 m
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	475 mm
Width	447 mm
Height	44.5 mm
Weight	10500 g
