Figure 20: Installed JNP10008-FAN2, with JNP10K-PWR-AC2 Power Supplies in an PTX10008 Router
g100650
1
2
2—1— Fan traysPower supplies
See Table 8 on page 48 for the physical specifications for the fan trays.
Table 8: Fan Tray Specifications
JNP10008-FAN2JNP10008-FANSpecification
JNP10008-FTC2JNP10008-FAN-CTLRCorresponding fan tray controller
model
Enhanced or standardEnhanced or standardChassis supported
2211Number of fans per fan tray
4422Number of fans per chassis
1793 CFM per fan tray1437.37 CFM per fan trayVolume flow at 100%
19.2R115.1X53-D30Introduced in Junos OS Release
22.4 in. (56.9 cm)22.4 in. (56.9 cm)Height
6.6 in. (16.8 cm)6.6 in. (16.8 cm)Width
