JVA ELECTRIC FENCE SYSTEMS
19
Technical Information
6.3 Jumpers
Jumper Function Purpose
J3 Inhibit Mains fail error.
intention is to operate the energizer on DC only
(as in solar power systems).
J4
Off to return programmable
options to factory defaults on
power up.
If the energizer needs to be defaulted to factory
settings, remove all power (AC and battery) and
the Energizer will be reset to default settings.
6.4 ConguringaZ114toruninBi-Polarmode
Step 1
On the back of the Z114 PCB near the high voltage output terminals there is a link
both points where it is soldered to prevent any arcing.
Step 2
Set Fence Mode (programming option 15)
to bipolar.
Value Function
0
1 Conventional
Z114 Programming Option 15
