JVA ELECTRIC FENCE SYSTEMS
8
Description
4.3 Front Panel LCD Display
The display on the JVA Z114 shows the voltage at the fence and return terminals.
The left is the return and the right is the feed voltage. Arrows at the top of the display

operation the left side is the positive Return Voltage and the right is the negative
Return Voltage.
The LCD also shows the programming option and current setting when in program
ming mode. This allows the programming options settings to be checked easily.
4.4 Inputs and Outputs
See Section 6.
4.5 Status Codes
See Section 6.2.
4.6 Keypad (Optional)
A keypad can be used to remotely monitor and control the Z114. It is also used to set
the programmable options for installer programming options, see Section 8.
4.7 Z Series Models
Z11 Single Zone, conventional 1.5 Joule.
Z13 Single Zone, conventional 2.8 Joule.
 
Z14R Z14 with relays and IR Tamper circuit.
 
circuit.
 
Z28 Dual Zone, conventional 8 Joule (4 Joules per zone).
ZM1 Single zone start of fence monitor with Distant Fault Detection™
ZM20 Twenty sector loop monitor
NOTE
