JVA ELECTRIC FENCE SYSTEMS
25
Keypad
number
Alarm Reduce Power
0 9.0 V 8.0 V
1 9.5 V 8.5 V
2 10.0 V 9.0 V
3 10.5 V 9.5 V
4 11.0 V 10.0 V
5 11.5 V 10.5 V
6 12.0 V 11.0 V
7 12.5 V 11.5 V
8 13.0 V 12.0 V
9 13.5 V 12.5 V
Battery Alarm Voltage (07x#)
Installation Programming Options
Value Cycles
0 1
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
Siren Cycles (10x#)
7.6.9 Siren Cycles (10x#)
This option sets the maximum number of times
the siren will sound for the “On time” if the alarm
continues. This may be limited by local regulations
to stop an alarm causing undue disturbance to
neighbours, etc.
NOTE: This is the maximum number of cycles for
1 continuous alarm, intermittent alarm events could
cause more than this number of siren soundings
7.6.10 Input Type (11x#)
The control inputs can be inverted. Unless
an input is used for a Gate switch, in which
case it is always NC.
7.6.11 Input 2 Function (12x#)
This option is used to set the function for the Control
Input “Gate”. If set to 0, the gate alarm will trigger if
the gate is opened for longer than the Gate Entry/
Exit Delay. If set to 1, the energizer will go into Low
Power Mode if this input is closed.
Value (x) Input type
0 NO Normally open
1 NC Normally Closed
Input Type (11x#)
Value Function
0 Gate
1 Low Power
Gate Input Function/
Low Power Mode (12x#)
7.6.12 Gate Entry/Exit Delay (13x#)
The gate switch must remain open for longer
than the Gate Entry/Exit Delay before the Gate
Alarm is triggered. If the switch closes within
this time, the Gate timer is reset to the Gate
Entry/Exit Delay value.
Notes:
1. Setting 0 was changed from 10 seconds to 0
(immediate) in rmware version 7.77.
2. From version 7.92 on, Option 18 may be
used to change this to a security panel style
entry/exit delay.
Value (x) Missed Pulses
0 0 Seconds (immediate)
1 30 Seconds
2 1 Minute
3 2 Minutes
4 3 Minutes
5 4 Minutes
6 5 Minutes
7 6 Minutes
8 7 Minutes
9 8 Minutes
Gate Entry/Exit Delay (13x#)
To Next Page
