JVA ELECTRIC FENCE SYSTEMS
43
Appendix A
APPENDIX A:
Group Simultaneous Pulse Feature
Group Simultaneous Pulse Feature
In some Industrial Installations it may be preferable to provide the ability to link
multiple Energizers into a group. When linked the individual Z Series Energizers
become a “Group”. Members of a group have simultaneous high voltage output
pulses and act as is they are one energizer with multiple outputs. This is designed
so that no possible combination of individual outputs can be dangerous.
1
Group Mode Programming (26x#)
A group MUST have only 1 master. The other Energizers
in the group are slaves.
For the Z114R Energizers, if there is no Master, a Slave
will display Error 4 on the Status LED when Armed and
it will not electrify the fence. This is a requirement for
Australian Standards.
each Slave will electrify the fence (pulses) when Armed.
However, the simultaneous pulse feature will NOT be
operating.
Note1: Do not interconnect the energizers via the
keypad bus until after they are programmed.
Note 2: If more than one keypad is used, they will need
different addresses (see 8.1.4: Changing the
keypad Messages and Address).
Note 3: If Perimeter Patrol is used any keypad in the
system should not have address 2, (see 8.1.4:
Changing the keypad Messages and Address).
For all Energizers that will be part of a group, the procedure is as follows:
1. Make sure the key switch is turned off and IN1 isn’t shorted (note that the
Z114R does not have a key switch).
2. Connect the battery.
3. On the keypad, enter [Installer’s code] [*] [0] [#].
4. Enter [26] followed by the required value (e.g. [1] for master) then [#].
5. Enter [*] [#] to exit programming.
6. Connect the group using the keypad bus as Group Mode Linking diagram.
Note 1: At this time groups are limited to a master and 14 slaves (15 zones total)
Value (x) Mode
0 No Group
1 Master
2 Slave 1
3 Slave 2
4 Slave 3
5 Slave 4
6 Slave 5
7 Slave 6
8 Slave 7
9 Slave 8
10 Slave 9
11 Slave 10
12 Slave 11
13 Slave 12
14 Slave 13
15 Slave 14
1
Patented.
