JVC GR-DVX8EG - Page 117

4-91
79 0 0
80 0 0
IC6401
1 4.8 4.8
20 0
3 1.2 1.2
4 4.5 4.5
5 4.8 4.8
Q6103
G 4.9 4.9
D 1.8 1.7
S 6.7 6.8
Q6104
G 5.7 5.6
D 0.9 1
S 6.7 6.7
Q6105
G 5.5 5.5
D 4.9 4.9
S 6.8 6.8
Q6106
G 2.7 2.7
D0 0
S 6.7 6.7
Q6107
G 1.8 1.8
D 4.9 4.9
S 6.7 6.7
Q6108
G4 4
D 3.1 3
S 6.7 6.7
Q6109
G 1.9 1.9
D3 3
S0 0
Q6110
G 4.8 4.8
D 1.8 1.8
S 6.7 6.7
Q6112
G 3.6 3.5
D 3 3.1
S 6.7 6.7
Q6113
G 0 1.6
D 3.1 3
S0 0
Q6201
14 4
2 4.6 4.6
3 0 15.1
44 4
5 4.5 4.5
6 15.6 0
Q6202
E 15.6 15.6
C 11.8 11.8
B 15 15.1
Q6203
E 14.8 14.8
C 15.6 15.7
B 15.5 15.5
Q6204
1 -7.1 -7.1
2 -7.6 -7.6
3 -11.5 -11.5
4 -7.1 -7.1
5 -7.6 -7.1
6 -15.9 -7.6
Q6205
E -12.1 -12.1
C -7.6 -7.6
B -11.5 -11.5
Q6206
E -15.3 -15.3
C -15.9 -15.9
B -15.8 -15.8
MODE
PIN NO.
REC PLAY
MODE
PIN NO.
REC PLAY
IC6101
1 0.4 0.4
2 0.4 0.4
3 0.4 0.4
4 1.1 1.1
51 1
6 1.5 1.5
7 4.3 4.3
8 1.5 1.5
9 0.6 0.7
10 1.5 1.5
11 3.1 3.1
12 0.8 0.8
13 0 0
14 0 0
15 0 0
16 0 0
17 0.7 0.7
18 0 0
19 0 0
20 0 0
21 0 0
22 5 5
23 6.8 6.7
24 0 0
25 5.6 5.6
26 6.8 6.8
27 1.3 1.3
28 0.5 0.5
29 0 0
30 0 0
31 1.5 1.5
32 6.7 6.7
33 4 4
34 2.1 2.1
35 0.5 0
36 0 0
37 1.9 1.9
38 0 0
39 4 4
40 6.7 6.7
41 3 3
42 3 2.9
43 3 3
44 2.3 2.3
45 1.5 1.5
46 0.9 0.9
47 1.8 1.8
48 1.5 1.5
49 0.8 0.8
50 2.3 2.3
51 1.5 1.5
52 0.9 0.9
53 0 0
54 0 0
55 1.5 1.5
56 1.1 1.1
57 3 3
58 1 1
59 0.4 0.4
60 0.4 0.4
61 6.7 6.7
62 4.8 4.8
63 0 0
64 0 0
65 0 0
66 6.7 6.7
67 3.6 3.5
68 0 0
69 1.6 1.6
70 0 0
71 0 0
72 6.7 6.7
73 1 1.8
74 0 0
75 6.7 6.7
76 2.7 2.7
77 0 0
78 6.8 6.7
MODE
PIN NO.
REC PLAY
<REG>
IC6601
1- -
2- -
3- -
4- -
5- -
6- -
7- -
8- -
Q6601
E- -
C- -
B- -
Q6602
1- -
2- -
3- -
4- -
5- -
Q6611
E- -
C- -
B- -
Q6612
1- -
2- -
3- -
4- -
5- -
Q6613
E- -
C- -
B- -
Q6614
1- -
2- -
3- -
4- -
5- -
Q6615
1- -
2- -
3- -
4- -
5- -
REC PLAY
<STROBE SUB>
MODE
PIN NO.
MODE
PIN NO.
REC PLAY
Q6207
E0 0
C 15.6 15.6
B -0.8 -0.9
IC6001
1 6.7 6.7
2 6.5 6.5
30 0
40 0
IC6002
10 0
2 6.7 6.8
3 3.3 3.3
40 0
50 0
IC6003
13 3
20 0
3 6.7 6.7
IC6004
1 3 2.6
23 3
30 0
40 0
Q6001
G0 0
D 6.7 6.8
S 6.8 6.7
Q6002
G 6.7 6.7
D0 0
S0 0
Q6003
G3 3
D0 0
S 3.9 3.9
Q6004
G0 0
D 6.5 6.5
S0 0
Q6005
G3 3
D0 0
S0 0
Q6006
G0 0
D 6.6 6.7
S 6.7 6.7
Q6007
10 0
23 3
3 6.8 6.8
4 6.8 6.8
50 0
MODE
PIN NO.
REC PLAY
<REG CTL>
IC8005
13 3
23 3
30 0
40 0
53 3
IC8006
13 3
20 0
3 1.3 1.2
4 2.5 2.5
53 3
IC8007
1 4.8 4.8
20 0
3 1.3 1.3
4 3.3 3.3
5 4.8 4.8
IC8008
1 1.4 1.4
2 1.4 1.4
33 3
40 0
50 0
6 1.5 1.5
7 1.3 1.1
83 3
IC8009
1- -
2- -
3- -
4- -
5- -
6- -
7- -
8- -
<DSC>
MODE
PIN NO.
REC PLAY
IC8102
10 0
23 3
3 1.2 0.5
4 3 3.1
53 3
63 3
7 3 3.1
80 0
93 3
10 0 0
11 3 3
12 0 0
13 1.1 0.5
14 3 3
15 0 0
16 3 3
17 0 0
18 3 3
19 3 3
20 3 3
IC8103
10 0
2 1.5 1.5
30 0
4 1.5 1.5
53 3
<AU DSP>
