FINAL ASSEMBLY <M2>
!
101 LY20576-004B LOWER CASE ASSY,A,B
!
LY20576-005B LOWER CASE ASSY,C,D,E,F
101A LY42536-001A SHEET(LOWER)
101B LY42259-001A SHEET(MIC C)
102 LY31764-001A BKT(TOP)
103 LY41675-001B RUBBER
106 LY20601-001B ARM ASSY
106A LY20594-001A BRACKET(ARM)
106B LY30001-023A TENSION SPRING
106D LY30018-056A SPECIAL SCREW,X2
106E LY42268-001A SPACER(SPK)
106F LY31678-001A BRACKET(HOOK)
106G LY31676-001A KNOB(EJECT)
106H LY31665-001A PLATE(LOCK)
106J LY30018-015A SPECIAL SCREW
107 LY30029-083A SPACER(A)
108 QAS0053-001 SPEAKER
109 LY30029-084A SPACER(A)
110 LY31762-001A HOLDER(SPK)
111 LY30029-085A SPACER(A)
112 LY40301-001A SPACER(SPK)
113 LY30029-086A SPACER(A)
114 LY31680-001B ZOOM UNIT,C,D
LY31680-002B ZOOM UNIT,A,B
LY31680-003B ZOOM UNIT,E,F
115 LY31671-001B MICROPHONE
116 LY30029-083A SPACER(A)
117 LY30029-094A SPACER(A)
121 LY20602-001A CASS.COVER ASSY,C,D,E,F
LY20602-003A CASS.COVER ASSY,A,B
121A LY31675-001A PLATE(HINGE),C,D,E,F
121B LY42261-001A BRACKET(HINGE),C,D,E,F
121C LY30014-009A SHAFT(C),C,D,E,F
121D LY30018-026A SPECIAL SCREW,X2
121E LY20599-001A COVER(C.C),C,D,E,F
LY20599-002A COVER(C.C),A,B
121F LY42434-001A SHEET(COVER)
122 LY41588-001A HOOK(OPE)
123 LY31745-001B GRIP BELT
124 LY10236-001A UPPER CASE
125 LY30029-091A SPACER(A),X2
126 LY42270-001A BATT.LOCK ASSY
126A LY30002-015A COMPRES. SPRING
127 LY31102-001A KNOB(LOCK)
128 LY41397-001A PLATE(KNOB)
129 LY42326-001A BRACKET(L/U)
130 LY42350-001A FOOT,X2
131 LY42272-001A SHEET(UPPER)
132 LY31682-001B LOCK(MONITOR)
!
133 LY41605-003A LABEL(UPPER)
134 LY31684-001A SUB OPE ASSY,C,D,E,F
135 LY20600-001A CAMERA OPE UNIT,C,D
LY20600-002A CAMERA OPE UNIT,E,F
LY20600-003A CAMERA OPE UNIT,A,B
136 LY31906-001A DECK OPE ASSY
137 LY41393-004A COVER(JIG CONN)
138 LY41701-002A SHEET(CAUTION)1
139 LY42163-003A SHEET(CAUTION)2
140 LY30029-099A SPACER(A)
141 LY42406-001A SHEET,A,B
!
146 LY20581-004E FRONT COVER ASSY,A,B
!
LY20581-005E FRONT COVER ASSY,C,D
!
LY20581-008A FRONT COVER ASSY,E,F
146A LY42276-001B INDICATOR
146B LY42277-001A WINDOW(IR)
146C LY42278-001A WINDOW(STB),C,D,E,F
146D LY31687-001A PAD
146E LY42280-001A SHEET(DF)
146F LY42281-001A COVER(DV)ASSY
146G LY42286-001A HINGE(AV)
146H LY42285-001A COVER(AV),E,F
LY42285-002A COVER(AV),A,B,C,D
147 LY31761-002B FRONT COVER2
151 LY31767-001A HOOD ASSY,C,D
LY31767-001B HOOD ASSY,A,B,E,F
152 LY31691-001B HOOK
153 LY42287-001A STUD(HOOK)
154 LY42404-001A SHEET
155 LY40698-002A LABEL(HOUSING)
156 LY40699-002A LABEL(PUSH)
157 LY30016-0H5A SPACER-A
158 LY30029-074A SPACER(A)
161 QYSPSPT1740R SCREW
162 LY30018-063A SPECIAL SCREW
163 QYSPSPT1740R SCREW,X2
164 QYSPSGT1740Z SCREW,X4
165 QYSPSGT1740Z SCREW
166 QYSPSPT1725Z SCREW,X2
167 LY30018-068A SPECIAL SCREW
168 LY30018-0B9A SPECIAL SCREW
169 LY30018-032A SPECIAL SCREW,X3
170 LY30018-020A SPECIAL SCREW,X4
171 LY30018-020A SPECIAL SCREW
172 LY30019-007B SPECIAL SCREW,X2
173 LY30018-060A SPECIAL SCREW
174 LY30018-093A SPECIAL SCREW
175 LY30018-026A SPECIAL SCREW
176 LY30018-060A SPECIAL SCREW,C,D,E,F
177 LY30018-043B SPECIAL SCREW
178 LY30018-032A SPECIAL SCREW,X2
179 LY30018-096A SPECIAL SCREW,X2
180 QYSPSPT1720R SCREW,X3
181 LY30018-066A SPECIAL SCREW,X6
182 LY30018-0B5A SPECIAL SCREW,X2
183 QYSPSPT1720R SCREW
184 LY30018-0B5A SPECIAL SCREW
191 LY30019-026A SPECIAL SCREW,X2
192 YQ43893-4 MINI SCREW
193 QYSPSPT1735R SCREW
194 YQ43893-4 MINI SCREW
195 QYSPSPT1735R SCREW
196 LY30018-070A SPECIAL SCREW
197 LY30018-049A SPECIAL SCREW,X5,A,B
LY30018-070A SPECIAL SCREW,X5,C,D,E,F
198 LY30019-023A SPECIAL SCREW
199 QYSPSPT1735R SCREW
200 QYSPSPT1720R SCREW
201 LY30018-070A SPECIAL SCREW
202 QYSPSPT1735R SCREW
203 QYSPSPT1735R SCREW
204 QYSPSPT1730R SCREW,X2,C,D
QYSPSPT1735R SCREW,X2,A,B,E F
205 LY30018-060A SPECIAL SCREW,A,B,C,D
LY30018-0B7A SPECIAL SCREW,E,F
206 LY30018-060A SPECIAL SCREW,A,B,C,D
LY30018-0B7A SPECIAL SCREW,E,F
207 QYSPSPT1735R SCREW
208 QYSPSPT1735R SCREW
209 LY30018-0B8A SPECIAL SCREW
210 LY30018-0B7A SPECIAL SCREW
211 QYSPSGT1780R SCREW,X2
212 LY30018-0B8A SPECIAL SCREW
213 QYSPSGT1712R SCREW
214 QYSPSPT1735R SCREW
215 LY30019-022A SPECIAL SCREW
216 QYSPSPT1735R SCREW,X2
217 LY30018-070A SPECIAL SCREW
221 LY20582-001A BRACKET(MECHA)
222 LY31758-001A FPC ASSY(M.CN)
223 LY31693-001A BASE(T.P.)
224 LY42290-001A BRACKET(BASE)1
225 LY42291-001A BRACKET(BASE)2,A,B,E,F
LY42291-001B BRACKET(BASE)2,C,D
226 QAL0240-001 FPC,MDA CN208-MMC CN601
227 WJT0034-001A E-CARD WIRE,AU/VF CN803-D.OPE
228 LY42756-001B HEAT TAPE
229 LY42748-001B SHIELD ASSY
229A LY42677-001A SHEET(CCD)
230 LY31696-001A SHIELD PLATE
231 LY30029-095A SPACER(A)
232 LY42770-001A SPACER(OP.M)
241 LY30483-001Q CASSETTE HOUSING ASSY
242 YQ43893-4 MINI SCREW,X3
243 LY41430-005A SPACER
244 LY30029-090A SPACER(A)
245 LY41430-004A SPACER
– OPTICAL BLOCK SECTION –
251 LYH20156-002A OPTICAL BLOCK ASSY
251A LY31572-001A ZOOM MOTOR
251B LY31571-001A FOCUS MOTOR
251C LY30727-002A SCREW,X5
251E LY30727-001A SCREW,X2
251F LY42110-001A OPTICAL LPF
251G LY30721-001A SPACER RUBBER
251H QYSPSGU1750Z SCREW,X2
251J LY31573-001A IRIS MOTOR UNIT
251K YS40168H CCD BASE ASSY
