JVC GR-DVX8EG - CCD Board Assembly <03; Monitor Board Assembly <04

5-22
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
R4822 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W
R4823 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4824 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R4825 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W
R4826 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R4827 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4828 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4833 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R4836 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4837 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4839 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4840 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4846 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4849 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4854 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4856 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4857 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4858 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W
R4859 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4860 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4862 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4863 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4864 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4865 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4866 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4867 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4868 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4870 NRSA6AJ-271W MG RESISTOR 270Ø,1/16W
R4871 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
R4874 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W
C1601 NCBA1CK-103W CAPACITOR 0.01µF,16V
C1602 NBE21AM-106X T CAPACITOR 10µF,10V
C1603 NBE21AM-106X T CAPACITOR 10µF,10V
C1605 NCBA1AK-104W CAPACITOR 0.1µF,10V
C1606 NCBA1HK-152W CAPACITOR 0.0015µF,50V
C1607 NCBA1AK-473W CAPACITOR 0.047µF,10V
C1614 NBE21AM-106X T CAPACITOR 10µF,10V
C1618 NCBA1HK-222W CAPACITOR 0.0022µF,50V
C1619 NCBA1HK-222W CAPACITOR 0.0022µF,50V
C1620 NCBA1HK-222W CAPACITOR 0.0022µF,50V
C1621 NCB21AK-105X CAPACITOR 1µF,10V
C1622 NCBA1CK-223W CAPACITOR 0.022µF,16V
C1623 NCBA1AK-473W CAPACITOR 0.047µF,10V
C1624 NCB31EK-103X CAPACITOR 0.01µF,25V
C1625 NCBA1AK-473W CAPACITOR 0.047µF,10V
C1626 NCBA1HK-331W CAPACITOR 330pF,50V
C1627 NCBA1CK-822W CAPACITOR 0.0082µF,16V
C1628 NCB21CK-224X CAPACITOR 0.22µF,16V
C1632 NBE21AM-106X T CAPACITOR 10µF,10V
C1633 NCF21CZ-684X CAPACITOR 0.68µF,16V
C1635 NCBA1AK-104W CAPACITOR 0.1µF,10V
C1641 NCB31AK-474X CAPACITOR 0.47µF,10V
C1801 NBE21AM-106X T CAPACITOR 10µF,10V
C4803 NBE90JM-106X T CAPACITOR 10µF,6.3V
C4804 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4805 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4806 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4808 NCB30JK-105X CAPACITOR 1µF,6.3V
C4809 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4810 NCFA1HZ-103W CAPACITOR 0.01µF,50V
C4811 NCFA1HZ-103W CAPACITOR 0.01µF,50V
C4812 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4813 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4814 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4815 NCB31HK-152X CAPACITOR 0.0015µF,50V
C4819 NCF31CZ-104X CAPACITOR 0.1µF,16V
C4851 NBE90JM-106X T CAPACITOR 10µF,6.3V
C4852 NCFA1AZ-104W CAPACITOR 0.1µF,10V
C4853 NBE91AM-335X T CAPACITOR 3.3µF,10V
C4854 NBE21AM-106X T CAPACITOR 10µF,10V
C4855 NCB31CK-104X CAPACITOR 0.1µF,16V
C4858 NDCA1HJ-680W CAPACITOR 68pF,50V
C4859 NCBA1HK-102W CAPACITOR 0.001µF,50V
C4860 NCBA1HK-102W CAPACITOR 0.001µF,50V
C4861 NCBA1HK-102W CAPACITOR 0.001µF,50V
C4862 NCBA1HK-102W CAPACITOR 0.001µF,50V
C4864 NBE90JM-106X T CAPACITOR 10µF,6.3V
C4865 NCBA1AK-104W CAPACITOR 0.1µF,10V
L1601 NQL315M-1R0X COIL 1µH
L4802 NQL302N-100X COIL 10µH
L4851 NQR0129-002X FERRITE BEAD
L4852 NQL315K-100X COIL 10µH
L4853 NQL315K-100X COIL 10µH
CN201 QGF0505F2-06X FPC CONNECTOR
CN202 QGF0517F2-11X FPC CONNECTOR
CN203 QGF0505F2-18X FPC CONNECTOR
CN204 QGF0507F1-15X FPC CONNECTOR
CN205 QGF0507F1-24X FPC CONNECTOR
CN206 QGB0401L1-80X CONNECTOR
CN207 QGF0505F2-07X FPC CONNECTOR
CN208 QGF0507F1-14X FPC CONNECTOR
OT1 LY30016-0E6A SPACER-A
✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
CCD BOARD ASSEMBLY <03>
PW YB10286A-02 CCD BOARD ASSY
Q5201 2SC3935/Q/-X TRANSISTOR
R5201 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W
C5202 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5203 NBEE1AM-226X T CAPACITOR 22µF,10V
C5204 NCB31CK-104X CAPACITOR 0.1µF,16V
C5205 NCB31CK-104X CAPACITOR 0.1µF,16V
C5206 NBZ0003-475X T CAPACITOR 4.7µF
C5207 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5208 NCB31HK-222X CAPACITOR 0.0022µF,50V
C5209 NCB21EK-104X CAPACITOR 0.1µF,25V
WR1 WJR0017-001A E-SH C WIRE C-F
✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
MONITOR BOARD ASSEMBLY <04>
PW1 YB10289B-01 MONITOR BOARD ASSY,A,C,D,E
YB10289B-02 MONITOR BOARD ASSY,B,F
IC7501 TL1451CPW IC
IC7502 TC7SH04FU IC(DIGITAL)
