2-5
A Cassette housing assembly T Fig. 2-2-12 3(S1),(L1a)-(L1d) 1a, 1b, 1c, 1d Adjustment
2a Reel disk (SUP) assembly T Fig. 2-2-13 (W2) 2a, 2b
2b Reel disk (TU) assembly T Fig. 2-2-13 (W2) 2a, 2b
2c Reel cover assembly T Fig. 2-2-13 (S2b),2(S2a),(W2) 2c, 2d
3a Tension arm assembly T Fig. 2-2-14 (W3a) 3b
3b Release guide assembly T Fig. 2-2-14 - 3a
3c Idler arm assembly T Fig. 2-2-14 (W3b) -
3d Guide arm assembly T Fig. 2-2-14 - 3a
3e Pinch roller arm assembly T Fig. 2-2-14 (W3a) -
4a Cleaner arm assembly T Fig. 2-2-15 (L4a) 4a
4b Slant pole arm assembly T Fig. 2-2-15 (W4),(L4b),(P4a),(P4b) 4b
4c Drum assembly T Fig. 2-2-15 3(S4) - Adjustment
5a Guide roller (S) assembly T Fig. 2-2-16 (P5) 5a, 5b Adjustment
5b Rail assembly T Fig. 2-2-16 3(W5a), (W5b) 5c, 5d
B Slide deck assembly / C Main deck assembly T Fig. 2-2-17 (W6),(L6a)-(L6d) 6a, 6b (Adjustment)
B Slide deck assembly
7a Loading brake assembly T Fig. 2-2-18 (W7),(L7a),(P7a) 7e Adjustment
7b Guide pin (SUPPLY) T Fig. 2-2-18 (S7a) -
7c Pad arm assembly T Fig. 2-2-18 (W7),(L7b),(P7b) 7d
7d Slide guide plate assembly T Fig. 2-2-18 (S7b) 7c Adjustment
7e Collar T Fig. 2-2-18 - 7a
7f Collar T Fig. 2-2-18 - 7a
7g Sub brake assembly T Fig. 2-2-18 (W7),(L7c),(P7c) 7b
7h Control plate assembly T Fig. 2-2-18 2(W7),(L7d),(P7d) 7b
C Main deck assembly
8a Tension lever assembly T Fig. 2-2-19 - 8c
8b Slide lever assembly T Fig. 2-2-19 - 8b
8c Brake control lever assembly T Fig. 2-2-19 - 8a
9a Loading guide T Fig. 2-2-20 (S9) -
9b Timing belt T Fig. 2-2-20 - 9b
9c Center gear assembly T Fig. 2-2-20 - -
9d Motor bracket assembly T Fig. 2-2-20 2(S9) 9a
9e Worm wheel T Fig. 2-2-20 (W9) - (Phase adjustment)
9f Gear holder T Fig. 2-2-20 (S9) -
10a Main cam gear T Fig. 2-2-21 (S10) 10b Phase adjustment
10b Brake control plate T Fig. 2-2-21 (L10) 10b Phase adjustment
10c Rotary encoder T Fig. 2-2-21 (S10),(W10a) 10a Phase adjustment
10d Connect gear T Fig. 2-2-21 (W10a) - (Phase adjustment)
10e Reel drive pulley assembly T Fig. 2-2-21 (W10b) -
11a Catcher (T) assembly T Fig. 2-2-22 2(S11) -
11b Capstan motor T Fig. 2-2-22 2(S11) -
11c Charge arm assembly T Fig. 2-2-22 (W11) 11
11d Sub cam gear T Fig. 2-2-22 (S11) - Phase adjustment
11e PWB holder B Fig. 2-2-22 2(S11) -
3. Disassembling procedure table
Step
Part Name Fig.
Point
Note
Remarks
Table 2-2-2
