Overlay Settings Menu
n
This screen is used to configure overlay settings.
Images can be overlaid onto recorded video and
live stream video.
(A P192
[Broadcast Overlay n
] )
Layout
For selecting a SDP file.
Memo :
0
Create a SDP file using SDP Generator in
Windows or Mac before recording.
Import User Layout
Load the SDP file that is created by using SDP
Generator onto this camera recorder.
Memo :
0
Maximum 4 files can be saved in this camera
recorder.
0
The SDP file may not be saved depending on
the available memory capacity of the camera
recorder.
Delete User Layout
For deleting the SDP file.
Memo :
0
The SDP file
is not deleted by selecting [System]
B [Reset All]. Delete the file from the camera
recorder.
Type
By selecting “Broadcast”, overlay images can be
displayed.
[Setting Values: Broadcast, RNone]
Output
For specifying overlay output settings.
9
HD Recording
For setting whether to record overlay images
together with the recorded video into an SD card.
0
On:
Saves the video
with overlay images into an SD
card.
0
Off:
Overlay images are not recorded into an SD
card.
[Setting Values: ROn, Off]
9
HDMI/SDI
For setting whether to display overlay images on
HDMI or SDI output.
0
On:
Displays overlay images on streaming videos
and HDMI/SDI output.
0
Off:
Displays overlay images only on streaming
videos.
[Setting Values: ROn, Off]
Watermark
Inserting watermarks (digital watermark) on
recorded videos protects
the content of your work.
0
On:
Displays watermark.
0
Off:
Does not display watermark.
[Setting Values: On, ROff]
9
Position
The display position of the watermark can be
changed by using the cross-shaped button.
Full Screen Graphic
Images can be displayed across the whole screen.
9
Status
For displaying the number of images saved in this
camera recorder and the memory capacity used.
(A P195 [Displaying Images on the Whole
Screen (Full Screen Graphic Function)] )
9
Import Graphic W / Y
For reading the images to be used in Full Screen
Graphic from an SD card.
Memo :
0
JPEG and PNG formats are supported.
0
Enter not more than 31 characters for the file
name.
9
Delete Graphic
For deleting all images saved in this camera
recorder.
Overlay Settings Menu n
