JVC GY-HM650U User Manual

Initial Settings
When
the power is first turned on, the Initial Setting
screen for performing the initial settings in the
camera recorder appears.
Set the date/time of the built-in clock in the [Initial
Setting] screen.
All operations are disabled until initial settings are
complete.
.
MODE
POWER
ON
OFF
(CHG)
AE LEVEL
MENU/THUMB
CANCEL
MENU/THUMB
CANCEL
Memo :
0
It
is recommended to use the AC adapter as the
power supply.
0
Be sure to close the lens cover.
1
Hold down the lock button (blue) at the
center of the [POWER ON/OFF(CHG)] switch
to set to “ON”.
A language selection screen appears.
0
For U models
.
0
For E models
.
Memo :
0
The menus and messages on the screen of the
LCD monitor or viewfinder are displayed in the
selected language.
2
Select a language using the cross-shaped
button (JK), and press the Set button (R).
The Initial Setting screen appears.
.
3
Ensure that the lens cover is closed, and
press the Set button (R).
0
Self-diagnosis starts.
0
A progress bar appears, and “Complete
Diagnosis
” appears when the diagnosis is
complete.
.
Memo :
0
It takes about 6 minutes to complete the
diagnosis. During the diagnosis, do not operate
or turn off the camera recorder.
32
Preparations

JVC GY-HM650U Specifications

General

Video Resolution	1920 x 1080
Audio Channels	2
HDMI Output	Yes
Component Output	Yes
Composite Output	Yes
FireWire	No
Image Stabilization	Optical
Filter Size	72 mm
Camera Type	Professional
Sensor Type	3x 1/3" CMOS
Effective Pixels	Approx. 2.07 megapixels (1920 x 1080)
Recording Format	AVCHD
Maximum Aperture	f/1.6
Minimum Focus Distance	1 m
ND Filter	Yes (1/4, 1/16)
Recording Media	SD/SDHC/SDXC
Audio Format	Linear PCM
LCD Screen	3.5-inch
Viewfinder	0.45"
Microphone Input	Yes, 2x XLR
Headphone Output	Yes, 1x 3.5mm
USB	Yes
Wireless	Optional
Battery Type	Lithium-ion
Battery Life	Approximately 3 hours with BN-VF823
Frame Rate	50i, 25p
