JVC GY-HM790U User Manual

1-2 (No.HC034<Rev.001>)
SPECIFICATION
GY-HM790U GY-HM790E GY-HM790CHU GY-HM790CHE
General
Power DC 12 V (10.5 V to 17 V)
Power consumption Approx. 26 W
(During recording [when the camera recorder + standard lens + LCD monitor are in use])
Mass Approx. 3.7 k g Approx. 3.9 k g Approx. 2.7 k g Approx. 2.8 k g
Allowable operating temperature 0
°C to 40 °C (32 °F to 104 °F)
Allowable operating humidity 30 % RH
Allowable storage temperature -20
°C to 60 °C (-4 °F to 122 °F)
Camera Section
Image pickup device 1/3" Progressive IT CCD
Color separation prism F1.4, 3-color separation prism
Sync system Internal sync (built-in SSG)
Lens mount 1/3" bayonet system
Optical filter OFF, 1/4, 1/16
Gain 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, ALC
Electronic shutter 1/6 to 1/10000, EEI
Variable frame 10/30-60/30fps, 10/25-50/25fps, 10/24-60/24fps
LCD monitor 4.3" LCD, 800 x 480 (WVGA, 410,000 pixels)
Viewfinder 0.45" LCOS, 1.22 megapixels(852 x 480 x 3)
Lens Section (GY-HM790U/GY-HM790E only)
Lens Canon F/1.6, 14x, f = 4.4-61.6 mm
( 35 mm conversion: 32-448 mm)
-
Filter diameter 82 mm -
Storage Section
Supported media SDHC (Class 6/10)
Slots x 2
Time Code
Time code signal Compliant with SMPTE/EBU
LTC input signal 1.0 Vp-p to 4.0 Vp-p, high impedance(unbalanced)
LTC output signal 1.0 Vp-p to 4.0 Vp-p, low impedance (unbalanced)
Terminal Section
[Y/VIDEO], [PB], and [PR] analog video out-
put terminals
Analog composite output (480i or 576i: Downconverted, 4: 3/16:9)
:1.0 V (p-p), 75 Ω, BNC (unbalanced)
Component output (720p/1080i) :
Y: 1.0 V(p-p), 75Ω
Pb, Pr: 0.7 V(p-p), 75 Ω, BNCx3 (unbalanced)
[HD/SD-SDI] output terminal (480i or 576i :
Downconverted / 720p /1080i: embedded
audio), BNC (unbalanced)
HD-SDI:Compliant with SMPTE 292 M
SD-SDI:Compliant with SMPTE 259 M
[AUDIO INPUT 1/2] terminal [MIC]:-60 dBu, 3k Ω , XLR (balanced),+48 V output (phantom power supply)
[LINE]:+4 dBu, 10k Ω , XLR (balanced)
[AUDIO OUTPUT] terminal -8 ± 1 dBu (when audio signal process output is -20 dB), 1 k Ω, RCA x2(unbalanced)
[PHONES] terminal 3.5 mm mini jack (stereo) x 2
[REMOTE] terminal 6-pin JVC remote control connection
[IEEE1394] terminal 4-pin
[USB] terminal Mini USB-B type, USB 2.0, miniB, slave function (mass storage class) only
[GENLOCK INPUT] terminal BB signal
SMPTE 170M(RS-170A) NTSC/ITU-R BT.470-6 PAL
HDTV 3 level synchronizing signal SMPTE 296 M/SMPTE 274 M BNC
[AUX INPUT] terminal Composite video signal
1.0 V (p-p), 75 Ω, BNC
- Composite video signal
1.0 V (p-p), 75 Ω, BNC
-
[STUDIO] terminal 10 pin
Video/Audio
Recording time Approx. 25 minutes (8 GB SDHC card, 35 Mbps, VBR mode)
Video recording file for-
mat
QuickTime File Format (For Final Cut Pro)
MP4 File Format (HD only)
AVI File Format (SD only)
Video signal HD (HQ mode):MPEG-2 Long GOP VBR, 35 Mbps (Max) MPEG-2 MP@HL
HD (SP mode):MPEG-2 Long GOP CBR, 25 Mbps (1440x1080i)/19 Mbps (1280x720p) MPEG-2 MP@H14
SD:DV CBR, 25 Mbps (720x480i)/(720x576i)
Audio signal LPCM 2ch, 48 kHz/16 Bit
Video format NTSC setting HD (HQ mode):1920x1080/59.94i, 29.97p, 23.98p, 1440x1080/59.94i (MOV only), 1280x720/59.94p, 29.97p, 23.98p
HD (SP mode):1440x1080/59.94i, 1280x720/59.94p, 29.97p, 23.98p
SD:720x480/59.94i - SD:720x480/59.94i -
PAL setting HD (HQ mode):1920x1080/50i, 25p, 1440x1080/50i (MOV only), 1280x720/50p, 25p
HD (SP mode):1440x1080/50i, 1280x720/50p, 25p
- SD:720x576/50i - SD:720x576/50i
Accessories
Viewfinder,Microphone, Lens,
Instructions, CD-ROM, War-
ranty Card
Viewfinder,Microphone, Lens,
Instructions, CD-ROM
Viewfinder,Microphone, In-
structions, CD-ROM, Warran-
ty Card
Viewfinder,Microphone, In-
structions, CD-ROM

JVC GY-HM790U Specifications

General

Sensor type	CCD
Total megapixels	- MP
Optical sensor size	1/3 \
Digital zoom	- x
Optical zoom	14 x
Image stabilizer	No
Focal length range	4.4 - 61.6 mm
Interchangeable lens	Yes
Focal length (35mm film equivalent)	32 - 448 mm
Camcorder media type	Memory card
Compatible memory cards	SDHC
Internal storage capacity	- GB
Built-in flash	-
Display diagonal	4.3 \
Display resolution	800 x 480 pixels
Display resolution (numeric)	410000 pixels
Viewfinder resolution	1226000 pixels
Viewfinder screen size	0.45 \
Camcorder type	Shoulder camcorder
Product color	Black
Video resolutions	1280 x 720, 1440 x 1080, 1920 x 1080 pixels
Supported video modes	1080i, 576i, 720p
Video formats supported	MPEG2
Maximum video resolution	1920 x 1080 pixels
Bitrate at maximum video resolution	35 Mbit/s
Maximum image resolution	- pixels
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) out	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Battery capacity	- mAh
Battery life (max)	- h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 85 %
Operating relative humidity (H-H)	30 - 80 %

Weight and Dimensions

Weight	3.7 g
