JVC GY-HM890e - Specifications

Specifications
General
Item Description
Power When using an external
power source:
DC 10.5 V to 17.0 V
When using a battery:
DC 14.4 V (Anton/Bauer,
IDX)
Power
consumption
Approx. 21.0 W
(during recording [camera
recorder + supplied lens]
while using the viewfinder)
Mass
GY-HM890U 3.95 kg (*1)
GY-HM890E 4.15 kg (*1)
GY-HM890CHU 2.7 kg (*2)
GY-HM890CHE 2.9 kg (*2)
GY-HM850U 3.9 kg (*1)
GY-HM850E 4.1 kg (*1)
GY-HM850CHU 2.65 kg (*2)
GY-HM850CHE 2.85 kg (*2)
Allowable
operating
temperature
0 °C to 40 °C (32 °F to 104 °F)
Allowable
operating humidity
35 %RH to 80 %RH
Allowable storage
temperature
-20 °C to 50 °C (-4 °F to 122
°F)
*1 Camera recorder (including microphone and
viewfinder) and supplied lens
*2 Camera recorder (including microphone and
viewfinder) only
Terminal Section
Video/Audio
Item Description
[HD/SD SDI OUT] Terminal (BNC)
HD-SDI
(1080i/720p)
Compliant with SMPTE 292 M
SD-SDI Compliant with SMPTE 259 M
3G-SDI Compliant with SMPTE 424 M
HD-SDI
embedded
audio
standard
Compliant with SMPTE 299 M
SD-SDI
embedded
audio
standard
Compliant with SMPTE 272 M
3G-SDI
embedded
audio
standard
Compliant with SMPTE 299 M
[HD/SD SDI IN] Terminal (BNC) A B
HD-SDI
(1080i/720p)
Compliant with SMPTE 292 M
SD-SDI Compliant with SMPTE 259 M
HD-SDI
embedded
audio
standard
Compliant with SMPTE 299 M
SD-SDI
embedded
audio
standard
Compliant with SMPTE 272 M
[VIDEO OUT]
Terminal (BNC)
1.0 V (p-p), 75 K (unbalanced)
[HDMI] Output
Terminal (Type
A)
V1.3-compliant
[INPUT1/INPUT2] Terminal (XLR 3-pin)
[MIC] -50 dBu, 3 kK, XLR (balanced),
+48 V output (phantom power
supply)
[LINE] +4 dBu, 10 kK, XLR (balanced)
[AUX] Terminal -22dBu, 10 kK, φ3.5 mm stereo
mini jack (unbalanced)
[AUDIO
OUTPUT CH-1/
CH-3] Terminal
-8 ± 1 dBu (during reference
level input), 1 kK (unbalanced)
[AUDIO
OUTPUT CH-2/
CH-4] Terminal
-8 ± 1 dBu (during reference
level input), 1 kK (unbalanced)
[PHONES]
Terminal
φ3.5 mm stereo mini jack
(unbalanced) x 2
Specifications
209
Others
