Need help?Do you have a question about the JVC KD-G401 and is the answer not in the manual?
Audio Amplifier| maximum power output (front) | 50 W per channel |
|---|---|
| maximum power output (rear) | 50 W per channel |
| continuous power output (RMS) (front) | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| continuous power output (RMS) (rear) | 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion |
| load impedance | 4 Ω (4 Ω to 8 Ω allowance) |
| tone control range (bass) | ±10 dB at 100 Hz |
| tone control range (treble) | ±10 dB at 10 kHz |
| frequency response | 40 Hz to 20 000 Hz |
| signal-to-noise ratio | 70 dB |
| line-out level/impedance | 2.0 V/20 kΩ load (full scale) |
| output impedance | 1 kΩ |
CD Player| operating voltage | DC 14.4 V (11 V to 16 V allowance) |
|---|---|
| allowable operating temperature | 0°C to +40°C |
| dimensions (W × H × D) | 182 mm × 52 mm × 150 mm |
| panel size | 188 mm × 58 mm × 11 mm |
| mass | 1.3 kg (excluding accessories) |
| frequency response | 5 Hz to 20 000 Hz |
| dynamic range | 96 dB |
| signal-to-noise ratio | 98 dB |
| max. bit rate | 320 Kbps |
Tuner| frequency range (FM) | 87.5 MHz to 108.0 MHz |
|---|---|
| frequency range (AM MW) | 522 kHz to 1 620 kHz |
| frequency range (AM LW) | 144 kHz to 279 kHz |
| usable sensitivity | 11.3 dBf (1.0 µV/75 Ω) |
| 50 dB quieting sensitivity | 16.3 dBf (1.8 µV/75 Ω) |
| alternate channel selectivity (400 kHz) | 65 dB |
| frequency response | 40 Hz to 15 000 Hz |
| stereo separation | 30 dB |
| capture ratio | 1.5 dB |
| sensitivity (MW) | 20 µV |
| selectivity (MW) | 35 dB |
| sensitivity (LW) | 50 µV |
