19
ESPAÑOL
Para la operación de los discos MP3, refiérase a
OPERACIONES DE MP3 en las páginas 24 a
27.
Reproducción de un CD
Inserte un CD en la ranura de carga.
La unidad se enciende,
el CD se introduce y la
reproducción se inicia
automáticamente.
Nota sobre la operación con pulsación única:
Si pulsa CD cuando hay un CD introducido en la
ranura de carga, la unidad se enciende y se empieza a
reproducir el disco automáticamente.
Todas las pistas se reproducen repetidamente
hasta que usted detenga la reproducción.
OPERACIONES DEL REPRODUCTOR DE CD
Notas:
Si inserta el CD boca abajo, aparecerá EJECT
en la pantalla y el CD será expulsado
automáticamente.
Si no hay CD en la ranura de carga, no se podrá
seleccionar CD como fuente. Aparecerá NO
DISC en la pantalla.
Si el disco actual es un CD Text, aparecerán
automáticamente el título del disco/ejecutante y
luego el título de la pista.
Para parar la reproducción y expulsar el CD
Pulse 0.
Se interrumpe la reproducción del CD, que será
expulsado automáticamente de la ranura de
carga. La fuente cambia a sintonizador (se
escuchará la emisora recibida en último
término).
Si cambia la fuente, la reproducción del CD
también se interrumpe (sin que el CD sea
expulsado).
La próxima vez que selecciona CD como
fuente, la reproducción del CD se iniciará
desde donde la detuvo.
Notas:
Si no saca el disco expulsado en unos 15 segundos,
será reinsertado automáticamente en la ranura de
carga para protegerlo del polvo.
(En este caso no se reproduce el disco).
Podrá expulsar el disco incluso cuando la unidad
esté apagada.
Tiempo de reproducción
transcurrido
Número de
pista actual
Número total de
pistas del disco
insertado
Tiempo de
reproducción total
del disco insertado
Indicación de la fuente actual
Indicador CD
SP19-22_KD-G401[EU]f.p65 24/11/03, 9:23 PM19

Table of Contents

Other manuals for JVC KD-G401

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G401 and is the answer not in the manual?

JVC KD-G401 Specifications

Audio Amplifier IconAudio Amplifier
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS) (front)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output (RMS) (rear)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range (bass)±10 dB at 100 Hz
tone control range (treble)±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player IconCD Player
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (W × H × D)182 mm × 52 mm × 150 mm
panel size188 mm × 58 mm × 11 mm
mass1.3 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner IconTuner
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz)65 dB
frequency response40 Hz to 15 000 Hz
stereo separation30 dB
capture ratio1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
