28
ESPAÑOL
AJUSTES DEL SONIDO
Indicación Para: Valores preajustados
BAS TRE LOUD
USER (Sonido 00 00 OFF
plano)
ROCK Música de +03 +01 ON
rock o disco
CLASSIC Música +01 02 OFF
clásica
POPS Música ligera +04 +01 OFF
HIP HOP Música de +02 00 ON
funk o rap
JAZZ Música de +02 +03 OFF
jazz
Nota:
Cada modo de sonido puede ajustarse según sus
preferencias. Una vez que se realice un ajuste, el
mismo será almacenado automáticamente para el
modo de sonido seleccionado actualmente. Consulte
Ajuste del sonido en la página 29.
Selección de los modos de
sonido preajustados (C-EQ:
ecualizador personalizable)
Puede seleccionar un modo de sonido
preajustado (C-EQ: ecualizador personalizable)
adecuado al género musical.
Hay un límite de tiempo para realizar los
siguientes pasos. Si se cancelan los ajustes
antes de haber terminado, comience otra vez
desde el paso
1
.
1
Pulse MODE para entrar en modo de
funciones.
2
Seleccione el modo de sonido
deseado.
Cada vez que pulsa el botón,
los modos de sonido cambian
de la siguiente manera:
Ej.: Cuando se selecciona ROCK
El patrón de indicación cambia para cada
modo de sonido, excepto para USER.
CLASSIC
POPSHIP HOPJAZZ
USER
ROCK
JAZZ
POPS
CLASSICROCKUSER
HIP HOP
SP28-29_KD-G401[EU]f.p65 24/11/03, 9:23 PM28

Table of Contents

Other manuals for JVC KD-G401

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G401 and is the answer not in the manual?

JVC KD-G401 Specifications

Audio Amplifier IconAudio Amplifier
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS) (front)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output (RMS) (rear)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range (bass)±10 dB at 100 Hz
tone control range (treble)±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player IconCD Player
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (W × H × D)182 mm × 52 mm × 150 mm
panel size188 mm × 58 mm × 11 mm
mass1.3 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner IconTuner
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz)65 dB
frequency response40 Hz to 15 000 Hz
stereo separation30 dB
capture ratio1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
