24
ESPAÑOL
Refiérase también a OPERACIONES DEL
REPRODUCTOR DE CD en las páginas 19 a 22.
Reproducción de un disco MP3
Inserte un disco MP3 en la ranura de
carga.
Nota sobre la operación con pulsación única:
Si pulsa CD cuando hay un disco introducido en la
ranura de carga, la unidad se enciende y se empieza a
reproducir el disco automáticamente.
Todos los archivos se reproducen repetidamente
hasta que usted detenga la reproducción.
OPERACIONES DE MP3
Notas:
Los discos MP3 requieren un mayor tiempo de
lectura.
(Difiere según la complejidad de la configuración
de carpeta/archivo).
Al iniciarse la reproducción, aparecerán
automáticamente los nombres de la carpeta y del
archivo (o etiquetas ID3). (Consulte también la
página 25).
Se interrumpirá la reproducción (sin que el disco
sea expulsado) si cambia la fuente o desconecta la
alimentación.
La próxima vez que selecciona el reproductor de
CD como fuente o se conecta la alimentación, la
reproducción del disco se iniciará desde el punto en
que se detuvo la reproducción previamente.
Para detener la reproducción y expulsar el
disco.
Pulse 0.
La reproducción se detiene y el disco se expulsa
automáticamente de la ranura de carga.
Ej.: Cuando el disco contiene 19 carpetas y
144 archivos MP3
Número total
de archivos
Número total
de carpetas
Indicador CD
Indicación de la fuente actual
Indicador MP3
SP24-27_KD-G401[EU]f.p65 24/11/03, 9:23 PM24

Table of Contents

Other manuals for JVC KD-G401

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G401 and is the answer not in the manual?

JVC KD-G401 Specifications

Audio Amplifier IconAudio Amplifier
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS) (front)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
continuous power output (RMS) (rear)19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion
load impedance4 Ω (4 Ω to 8 Ω allowance)
tone control range (bass)±10 dB at 100 Hz
tone control range (treble)±10 dB at 10 kHz
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player IconCD Player
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (W × H × D)182 mm × 52 mm × 150 mm
panel size188 mm × 58 mm × 11 mm
mass1.3 kg (excluding accessories)
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
max. bit rate320 Kbps
Tuner IconTuner
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (400 kHz)65 dB
frequency response40 Hz to 15 000 Hz
stereo separation30 dB
capture ratio1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
