17
English
Sound Adjustments Using MULTI JOG Dial
You can adjust the sound using MULTI JOG dial on the front
panel.
• Tone—BASS, TREBLE
• Subwoofer output level*—SUBWFR LEVEL
• Speakers’ output level*—
FRONT L/R LEVEL, CENTER LEVEL, SURR L/R LEVEL
• Effect level for DAP modes—EFFECT
• Panorama control for Pro Logic II Music—PANORAMA
CTRL
* You can also use the remote control to adjust these items
(see pages 18 and 19).
7 Operating buttons
Buttons To do
ADJUST Enter the receiver into the sound adjusting
mode.
MULTI JOG • Select an item to adjust after pressing
ADJUST.
• Adjust the selected item after pressing
SET.
SET Determine the item to adjust.
EXIT Exit from the sound adjusting mode or
return to the previous step.
7 Operating procedure
Ex. When adjusting the bass sound
Before you start, remember...
There is a time limit in doing the following steps. If the setting
is canceled before you finish, start again from step
1
.
1
Press ADJUST.
The last selected item appears on the display.
2
Turn MULTI JOG dial to select an item you
want to adjust.
*
These items may not be selected depending on how the
following are set:
• Subwoofer setting
• Speaker size setting
• The current Surround/DSP mode
For details, see the next page and “Adjustable items and
selected Surround/DSP mode” on page 25.
3
Press SET.
The current setting of the selected item appears on the
display.
EX.: When “BASS” is selected.
4
Turn MULTI JOG dial to select an
appropriate value.
Adjust the bass sound level within the range of –10 dB to
+10 dB.
EX.: When the bass level is adjusted to “+4.”
5
Press EXIT.
To adjust other items, repeat steps
2
to
5
.
To finish the adjustment, go to step
6
.
6
Press EXIT again.
The receiver exits from the sound adjusting mode.
BASS
TREBLE
SUBWFR LEVEL*
FRONT L LEVEL
FRONT R LEVEL
CENTER LEVEL*
SURR L LEVEL*
SURR R LEVEL*
EFFECT*
PANORAMA CTRL*
(back to the beginning)
OO O
O
O
O
O
O
O
O
Sound Adjustments
SETTING
MULTI JOG
SET
ADJUST
EXIT
16-21_RX-5032V[US]f 03.2.5, 18:5817
