Parts Identification
See pages in parentheses for details.
1 STANDBY/ON button and STANDBY lamp (10, 20)
2 SURROUND/DSP OFF button (24, 25)
3 DSP button (25)
4 SURROUND button (24)
5 Remote sensor (9)
6 Display (For details, see “Display” below.)
7 • INPUT ANALOG button (15)
• INPUT ATT (attenuator) button (16)
8 INPUT DIGITAL button (15)
9 DIMMER button (12)
p MASTER VOLUME control (11)
q PHONES jack (11)
Front Panel
w • Source selection buttons (10)
DVD, VCR, TV SOUND, CD, TAPE/CDR, FM/AM
• SOURCE NAME button (10)
e SPEAKERS ON/OFF button (11)
r SUBWOOFER OUT ON/OFF button (16)
t FM/AM TUNING 5/∞ buttons (20)
y FM/AM PRESET 5/∞ buttons (20, 21)
u FM MODE button (21)
i MEMORY button (20, 21)
o SETTING button (13)
; SET button (13, 17)
a MULTI JOG dial (13, 17)
s EXIT button (13, 17)
d ADJUST button (17)
Display
See pages in parentheses for details.
1 ANALOG indicator (15)
2 DIGITAL AUTO indicator (15)
3 SPK (speaker) indicator (11)
4 Speaker indicators and signal indicators (25)
5
PRO LOGIC II indicator (22, 24)
6 DSP indicator (23, 25)
7 H.PHONE indicator (11)
8 INPUT ATT (attenuator) indicator (16)
9 TUNED indicator (20)
0 STEREO indicator (20)
- AUTO MUTING indicator (21)
= SLEEP indicator (12)
~ VOLUME indicator (12)
! Digital signal format indicators (15)
@ CH– indicator (20)
# Main display
STANDBY
STANDBY/ON
PHONES
SURROUND
DSP
SPEAKERS
ON/OFF
SUBWOOFER OUT FM MODE MEMORY
ON/OFF
FM/AM TUNING
SURROUND/DSP
OFF
DIMMER
MASTER VOLUME
INPUT DIGITAL
RX–5032V AUDIO/VIDEO CONTROL RECEIVER
SETTING
MULTI JOG
SET
ADJUST
EXIT
INPUT ANALOG
INPUT ATT
FM/AM PRESET
DIGITAL
PRO LOGIC
1234
5
q
ew
r
ui
o;
asd
ty
DVD
VCR
CD
FM/AM
TAPE/CDR
TV SOUND
6
7
89
p
SOURCE NAME
1234 5 67 8 =-09
!
~
@#
