Specifications
Amplifier
Output Power At Stereo operation
Front Channels 80 watts per channel, min. RMS, both channels driven into 4
ohms at 1 kHz with no more than 0.9% total harmonic distortion.
(IEC268-3/DIN)
70 watts per channel, min. RMS, both channels driven into 8
ohms at 1 kHz with no more than 0.9% total harmonic distortion.
(IEC268-3/DIN)
65 watts per channel, min. RMS, both channels driven into 8
ohms, 20 Hz to 20 kHz with no more than 0.06% total harmonic
distortion.
At Surround operation
Front Channels 70 watts per channel, min. RMS, driven into 8 ohms at 1 kHz with
no more than 0.7% total harmonic distortion.
Center Channel 70 watts, min. RMS, driven into 8 ohms at 1 kHz, with no more
than 0.7% total harmonic distortion.
Rear Channels 70 watts per channel, min. RMS, driven into 8 ohms at 1 kHz,
with no more than 0.7% total harmonic distortion.
Total Harmonic Distortion 0.06 %* at 65 watts output
(8 ohms, 1 kHz) (* Measured by JVC Audio Analysis System)
Audio Input Sensitivity/ PHONO (MM) 2.5 mV/47 k ohms
Impedance (1 kHz) CD, VCR, VIDEO1, VIDEO2, 230 mV/47 k ohms
TV SOUND, TAPE
Audio Output Level TAPE, VCR 230 mV
Signal-to-Noise Ratio PHONO 70 dB/66 dB
(’66 IHF/DIN) CD, VCR, VIDEO1, VIDEO2, 87 dB/67 dB
TV SOUND, TAPE
Frequency Response (8 ohms) PHONO 20 Hz to 20 kHz (±1 dB)
CD, VCR, VIDEO1, VIDEO2, 20 Hz to 20 kHz (±1 dB)
TV SOUND, TAPE
RIAA Phono Equalization ±0.5 dB (20 Hz to 20 kHz)
Loudness Control +6 ±1 dB at 100 Hz
(Volume Control at –40 dB) +4 ±1 dB at 10 kHz
S.E.A. Center Frequencies 100 Hz, 1 kHz, 10 kHz
Control Range ±10 dB ±2 dB
Video
Video Input Sensitivity/Impedance VCR, VIDEO1, VIDEO2 1 Vp-p/75 ohms
Video Output Level VCR, MONITOR OUT 1 Vp-p (at 1 Vp-p input)
Synchronization Negative
Signal-to-Noise Ratio 45 dB
On-Screen Color System PAL
