10 1 Li up the latch of the Inner casing to unlock.
2 Turn the casing 60 degrees le to release it from the
flange.
11 Li the Inner casing away from the sensor head.
12 Power off the DTR. Connect sensor cable to the DTR.
1 Take off sensor nameplate and the gasket
underneath.
2 Put interconnecng cable through the cable gland.
3 Connect the interconnecng cable to the sensor.
4 Screw the cable gland to the sensor.
5 Fit the gasket and nameplate onto the sensor and
screw the nameplate back on.
Turn on DTR power to power up the Safe-Drive™
system.
