PR-23 instrucon manual
9.4 Sanitary probe refractometer PR-23-AP
9.4.1 PR-23-AP model code
MODEL AND DESCRIPTION MODEL
PR-23 = Sensor PR-23
Sensor model
-A = 3A approved -A
Sensor type
P = Probe type for tanks and large pipes P
Refracve Index range limits
-62 = n
D
1.320–1.530 (0–100 Brix) -62
-74 = n
D
1.260–1.470, Sapphire prism -74
-82 = n
D
1.410–1.620, YAG prism -82
-92 = n
D
1.520–1.730, GGG prism -92
Process connecon
-T = Sanitary 3A clamp, 2 1/2 inch, inseron length 170 mm -T
-I = Sanitary 3A clamp, 2 1/2 inch, inseron length 42 mm -I
-R = Sanitary 3A clamp, 4 inch, inseron length 170 mm -R
-S = Sanitary 3A clamp, 4 inch, inseron length 63 mm -S
-P = MT4 DN 25/1T APV Tank boom flange, flush mounted -P
-B = MT4 DN 25/1T APV Tank boom flange, inseron length 170 mm -B
-V = Sanitary 3A clamp, 2 1/2 inch, inseron length 170 mm -V
-H = Sanitary 3A clamp, 2 1/2 inch -H
-Q = Sanitary 3A clamp, 2 1/2 inch for flush-mount adaptor, inseron length 139.5 mm -Q
-C = Varivent
®
in-line access unit clamp DN 65, inseron length 170 mm -C
-ZP = Sanitary I-line male (14 WI) 2 1/2” , inseron length 178 mm -ZP
Sensor weed parts material
SS = AISI 316 L SS
HA = Alloy 20 HA
Electrical classificaon
-GP = General Purpose -GP
-AX = ATEX cerfied EX II 3 G Eex nA II T4 (up to Zone 2) -AX
-IA = ATEX and IECEx cerfied EX II 1 G Ex ia II C T4 Ga (up to Zone 0) -IA
Sensor housing
-AA = Anodized aluminium -AA
-SC = Stainless steel -SC
9.4.2 PR-23-AP mounng hardware model code
MODEL AND DESCRIPTION MODEL
VFMA-23-PSS = MT4 DN25/1T APV tank boom flange for PR-23-AP VFMA-23-PSS
VFBP-23-PSS = Blind flange for MT4 DEN 25/1T APV tank boom flange VFBP-23-PSS
VFME-23-VSS = Mount adaptor for PR-23-AP-62-VSS HEXNUT type VFME-23-VSS
VFMF-23-VSS = Mount adaptor for PR-23-AP-62-VSS HEXNUT extended VFMF-23-VSS
