160
PR-23 instrucon manual
10 Take a firm grip on the hand wheel and the handle and
pull out the Safe-Drive™ Retractor with the sensor
inside.
Warning! A firm hold of the tool is essenal as the
combinaon of the tool and the sensor is noceably
heavier than Retractor alone.
Note: To ensure the isolaon valve aer the
Safe-Drive tool with the sensor have been removed,
you can bolt a standard ANSI 1.5" 105 lbs blind flange to
it with 1/2" (M12) bolts and nuts.
A lock can be added to the isolaon valve handle.
Warning! The sensor p is hot and may be covered
with liquor. It is recommended to rinse the sensor p
and the isolaon valve with hot water.
11
1
2
11
Put the Safe-Drive™ Retractor with sensor onto a table
or similar surface so that the hand wheel has space to
turn.
1 Turn the wheel counterclockwise unl the
trapezoidal thread is all the way inside the Outer casing
and loose from the wheel, i.e. the Outer casing is no
longer connected to the parts inside.
2 Pull the Outer casing off.
12
1
2
3
12
1 Open the latch on the Inner casing.
2 Keep sensor steady with one hand and turn the Inner
casing counterclockwise with the other hand to unlock
the Inner casing from sensor.
3 Pull off the sensor.
