6 Configuraon and calibraon
53
Theother
sensor
washing?
NO
YES
MANUAL
W
ASH been
pressed?
NO
YES
Remote
wash
requested?
1
NO
YES
Wash
interval
reached?
YES
NO
Temp
limit
active?
YES
NO
Temp
above
limit?
YES
NO
Message
NOSAMPLE?
2
NO
YES
Washcycle
Rest
artwash
intervaltimer
NOTES
1.
Remotewashistriggeredat
theclosingoftheswitch.If
theswitchisheldclosed,
onlyonewashcycleis
carriedout.
2. Thewashisinhibitedif
thereisnosample,no
sensororthesensorcannot
measurecorrectly.
Figure 6.15 Wash logic
