K-TRON K-Commander User Manual

805.44
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 05: Scale Programming and Weight Span
Introduction:
Page 05;
The page 05 for the loss-in-weight feeder holds the information
regarding the weighing system and the calibration and tare functions
for it. Use the Scroll keys to move from page to page.
Page 05 layout
This diagram shows the data layout. The second row of keys pop up
when the Edit key is pressed and a variable is highlighted.
F5 F6 F7 F8
Edit
Mode
F1 F2 F3
F4
Grav
Mode
Vol
Mode
POWDER LWF : Scale Programming M01.05
SCALE GROSS WEIGHT RANGE 300.000 Kg
MEASURED GROSS WEIGHT 281.789 Kg
MATERIAL NET WEIGHT 130.670 Kg
FEEDER TARE WEIGHT 151.119 Kg
WEIGHT SPAN 1.000
F5 F6 F7 F8
Change
Value
<ESC>
T
Continued on next page
