K-TRON K-Commander User Manual

805.55
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 07: Feeder Setup Data
Introduction:
Page 07
The page 07 for the loss-in-weight feeder holds the information that
scales the feeder system. Use the Scroll keys to move from page to
page.
Page 07 layout
This diagram shows the data layout. The second row of keys pop up when
the Edit key is pressed and a variable is highlighted.
F5 F6 F7 F8
Edit
Mode
F1 F2 F3
F4
Grav
Mode
Vol
Mode
POWDER LWF : Feeder Data M01.07
FULL SCALE SETPOINT 2000.000 Kg/Hr
UNITS SELECTION Kg/Hr
EXT. TOTALIZER INCR. 1.000 Kg
FEEDER TYPE SELECTION LWF120
SPEED PICKUP GEAR TEETH 120
TOTAL GEAR REDUCTION 1.000
FEEDER MODE Local
FULL SCALE DRIVE COMMAND 10000 Hz
PROGRAMMING PRIORITY LCD Locked Out
SERVICE VARIABLE INDEX Full Scale Drive Command
SERVICE VARIABLE VALUE 10000.0000
F5 F6 F7 F8
Change
Value
<ESC>
Continued on next page
