K-TRON K-Commander User Manual

805.70
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 08: Frequency I/O
Introduction
Page 08
The page 08 for the loss-in-weight feeder holds the information that
programs the Frequency I-O functions. Use the Scroll keys to move
from page to page.
Page 08 layout
This diagram shows the data layout. The second row of keys pop up when
the Edit key is pressed and a variable is highlighted.
Edit
Mode
F5 F6 F7 F8F1 F2 F3
F4
POWDER LWF : Frequency I-O M01.08
FREQUENCY OUTPUT #1 Not Assigned
FREQUENCY OUTPUT #2 Not Assigned
FREQUENCY OUTPUT #3 Not Assigned
FREQUENCY INPUT #1 Not Assigned
FREQUENCY INPUT #2 Not Assigned
FREQUENCY INPUT #3 Setpoint
FREQ INPUT #1 VALUE 0.000 Hz
FREQ INPUT #2 VALUE 0.000 Hz
FREQ INPUT #3 VALUE 0.000 Hz
SCALED FREQ INPUT #3 0.000 Hz
SCALE FACTOR INPUT #3 1.000
FREQ IN #3 DEADBAND 1 Hz
Grav
Mode
Vol
Mode
F5 F6 F7 F8
Change
Value
<ESC>
Continued on next page
