805.89
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
Alarm Shutdown Masking
Introduction
The Alarm Shutdown Mask allows the user to select the alarms that
will not activate the alarm shutdown output. This is done using the
K10S ASR word and calculating the decimal value and then entering
that value in the Service Variable Value on the K-Commander. Below is
a list of alarms for LWF with an example.
Bit Function Decimal Value
0 Feedfactor alarm 1
1 External alarm active 2
2 Unassigned 4
3 Lo Motor Gain 8
4 Unassigned 16
5 Unassigned 32
6 Battery Low 64
7 Nak'd due to feeder running 128
8 Net Weight Low alarm 256
9 Scale Overrange 512
10 Scale Underrange 1,024
11 Refill Timer Expired 2,048
12 Rate > Setpoint 4,096
13 Rate < Setpoint 8,192
14 Drive Command > DHS 16,384
15 Drive Command < DLS 32,768
16 Ext. Channel Range Error 65,536
17 Ext. Channel Invalid Command 131,072
18 Ext. Channel Fail 262,144
19 Int. Channel Range Error 524,288
20 Int. Channel Failure 1,048,576
21 Weight Processor Failure 2,097,152
22 Unassigned 4,194,304
23 MDU alarm 8,388,608
Total
16,777,215
(all alarms)
Continued on next page
