Document Number 481.093 Rev. A - 06/04
22
SPECIFICATIONS
Electronic Specifications
Power Unit: Solenoid
Power: Self power by pressing outside lever
Hardware Specifications
Dimensions: Outside case: 3 1/2” x 9 1/4” x 2 3/8” (89mm x 235mm x 60mm);
Inside case: 3 1/2” x 9 3/4” x 1 3/4” (89mm x 248mm x 44mm)
Cover Material: Cast zamak
Handing: Non-handed
Door Thickness: 1 3/8” - 2” (35mm-50.8mm)
Backset: 2 3/4” (70mm)
Latchbolt: 9/16” (14.3mm) throw (Optional 3/4” (19mm) throw also available.)
Strike: 2 3/4” (70mm) T-strike or 4 7/8” (124mm) ASA strike
Lever: Solid cast zamak, return to within 1/2” (12.7mm) of door face
Key Cylinder/Cores:
Standard: 6-pin conventional (brushed chrome finish)
Optional: IC Core, 6-pin (brushed chrome finish) - furnished by customer
IC Core, 7-pin (brushed chrome finish) - furnished by customer
Keys: Nickel silver (2)
Finishes - BHMA:
Covers: Black powder coat, satin chrome (US26D)
Levers: Satin chrome (US26D)
Certifications/ ANSI/BHMA A156.2
Compliance: 3-hour UL/ULC
Fire Door Rating
ADA
Shipping Weight:14 lbs.
